FT-F Series Metal Sheet Laser Cutting Machine

1. Single platform laser cutting machine;
2. Simple and convenient operation;
3. Easy installation and small footprint;
4. Stable work and high efficiency;
5. Power segment: 1kw to 30kw;
6. Working area: 3000mm*1550mm to 12000mm*2550mm;
7. Can be configured with IPG/MAX/RAYCUS laser, Raytools/Precitec and other brand laser heads.
Availability:
Quantity:
Inquire Add to Basket

  • FT-F Series Metal Sheet Laser Cutting Machine

  • Glorious-FT

Technical Parameter

Model

FT-F series Single Platform Laser Cutting Machine

Working format (mm)

3015

4015

4020

6020

6025

8025

12025

Personalization

Power (KW)

1kw—6kw

3kw—12kw

6kw—30kw

1kw—30kw

Maximum cutting area (mm)

3000mm*1524mm — 12000mm*2550mm

X/Y  positioning accuracy

±0.03mm

X/Y  repeatability

±0.02mm

X&Y Max. linkage speed

100 m/min—150m/min

Maximum acceleration

1.5G

Loading capacity

2600kg-18000kg

Processing material

Carbon Steel/Stainless Steel/Lu alloy/Copper

Total Power

*****KW/A
